This is a specialization on VertexTransform that returns the transform necessary to move vertices as if they were assigned to the indicated joint. More...
#include "jointVertexTransform.h"
Public Member Functions | |
| JointVertexTransform (CharacterJoint *joint) | |
| Constructs a new object that converts vertices from the indicated joint's coordinate space, into the other indicated joint's space. More... | |
| virtual void | accumulate_matrix (LMatrix4 &accum, PN_stdfloat weight) const |
| Adds the value of this transform's matrix, modified by the indicated weight, into the indicated accumulation matrix. More... | |
| virtual int | complete_pointers (TypedWritable **plist, BamReader *manager) |
| Receives an array of pointers, one for each time manager->read_pointer() was called in fillin(). More... | |
| virtual TypeHandle | force_init_type () |
| const CharacterJoint * | get_joint () const |
| Returns the joint for which this object returns the transform. More... | |
| virtual void | get_matrix (LMatrix4 &matrix) const |
| Stores the transform's matrix in the indicated object. More... | |
| virtual TypeHandle | get_type () const |
| virtual void | mult_matrix (LMatrix4 &result, const LMatrix4 &previous) const |
| Premultiplies this transform's matrix with the indicated previous matrix, so that the result is the net composition of the given transform with this transform. More... | |
| virtual void | output (std::ostream &out) const |
| virtual void | write_datagram (BamWriter *manager, Datagram &dg) |
| Writes the contents of this object to the datagram for shipping out to a Bam file. More... | |
 Public Member Functions inherited from VertexTransform | |
| UpdateSeq | get_modified (Thread *current_thread=Thread::get_current_thread()) const |
| virtual void | write (std::ostream &out, int indent_level) const |
| Public Member Functions inherited from TypedWritableReferenceCount | |
| TypedWritableReferenceCount (const TypedWritableReferenceCount ©) | |
| virtual ReferenceCount * | as_reference_count () |
| Returns the pointer cast to a ReferenceCount pointer, if it is in fact of that type. More... | |
| void | operator= (const TypedWritableReferenceCount ©) |
| Public Member Functions inherited from TypedWritable | |
| TypedWritable (const TypedWritable ©) | |
| vector_uchar | encode_to_bam_stream () const |
| Converts the TypedWritable object into a single stream of data using a BamWriter, and returns that data as a bytes object. More... | |
| bool | encode_to_bam_stream (vector_uchar &data, BamWriter *writer=nullptr) const |
| Converts the TypedWritable object into a single stream of data using a BamWriter, and stores that data in the indicated string. More... | |
| virtual void | finalize (BamReader *manager) |
| Called by the BamReader to perform any final actions needed for setting up the object after all objects have been read and all pointers have been completed. More... | |
| UpdateSeq | get_bam_modified () const |
| Returns the current bam_modified counter. More... | |
| void | mark_bam_modified () |
| Increments the bam_modified counter, so that this object will be invalidated and retransmitted on any open bam streams. More... | |
| void | operator= (const TypedWritable ©) |
| virtual bool | require_fully_complete () const |
| Some objects require all of their nested pointers to have been completed before the objects themselves can be completed. More... | |
| virtual void | update_bam_nested (BamWriter *manager) |
| Called by the BamWriter when this object has not itself been modified recently, but it should check its nested objects for updates. More... | |
| Public Member Functions inherited from TypedObject | |
| TypedObject (const TypedObject ©)=default | |
| TypedObject * | as_typed_object () |
| Returns the object, upcast (if necessary) to a TypedObject pointer. More... | |
| const TypedObject * | as_typed_object () const |
| Returns the object, upcast (if necessary) to a TypedObject pointer. More... | |
| int | get_best_parent_from_Set (const std::set< int > &) const |
| int | get_type_index () const |
| Returns the internal index number associated with this object's TypeHandle, a unique number for each different type. More... | |
| bool | is_exact_type (TypeHandle handle) const |
| Returns true if the current object is the indicated type exactly. More... | |
| bool | is_of_type (TypeHandle handle) const |
| Returns true if the current object is or derives from the indicated type. More... | |
| TypedObject & | operator= (const TypedObject ©)=default |
| Public Member Functions inherited from ReferenceCount | |
| int | get_ref_count () const |
| WeakReferenceList * | get_weak_list () const |
| Returns the WeakReferenceList associated with this ReferenceCount object. More... | |
| bool | has_weak_list () const |
| Returns true if this particular ReferenceCount object has a WeakReferenceList created, false otherwise. More... | |
| void | local_object () |
| This function should be called, once, immediately after creating a new instance of some ReferenceCount-derived object on the stack. More... | |
| void | ref () const |
| Explicitly increments the reference count. More... | |
| bool | ref_if_nonzero () const |
| Atomically increases the reference count of this object if it is not zero. More... | |
| bool | test_ref_count_integrity () const |
| Does some easy checks to make sure that the reference count isn't completely bogus. More... | |
| bool | test_ref_count_nonzero () const |
| Does some easy checks to make sure that the reference count isn't zero, or completely bogus. More... | |
| virtual bool | unref () const |
| Explicitly decrements the reference count. More... | |
| WeakReferenceList * | weak_ref () |
| Adds the indicated PointerToVoid as a weak reference to this object. More... | |
| void | weak_unref () |
| Removes the indicated PointerToVoid as a weak reference to this object. More... | |
Static Public Member Functions | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| static void | register_with_read_factory () |
| Tells the BamReader how to create objects of type JointVertexTransform. More... | |
| Static Public Member Functions inherited from VertexTransform | |
| static TypeHandle | get_class_type () |
| static UpdateSeq | get_global_modified (Thread *current_thread) |
| Returns the currently highest VertexTransform::get_modified() value in the world. More... | |
| static UpdateSeq | get_next_modified (Thread *current_thread) |
| Returns a monotonically increasing sequence. More... | |
| static void | init_type () |
| Static Public Member Functions inherited from TypedWritableReferenceCount | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| static | PT (TypedWritableReferenceCount) decode_from_bam_stream(vector_uchar data |
| Static Public Member Functions inherited from TypedWritable | |
| static bool | decode_raw_from_bam_stream (TypedWritable *&ptr, ReferenceCount *&ref_ptr, vector_uchar data, BamReader *reader=nullptr) |
| Reads the bytes created by a previous call to encode_to_bam_stream(), and extracts the single object on those bytes. More... | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| Static Public Member Functions inherited from TypedObject | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| This function is declared non-inline to work around a compiler bug in g++ 2.96. More... | |
| Static Public Member Functions inherited from ReferenceCount | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
Friends | |
| class | CharacterJoint |
Additional Inherited Members | |
| Public Attributes inherited from VertexTransform | |
| get_modified | |
| Returns a sequence number that's guaranteed to change at least every time the value reported by get_matrix() changes. More... | |
| Public Attributes inherited from TypedWritableReferenceCount | |
| static BamReader * | reader = nullptr) |
| Public Attributes inherited from TypedObject | |
| get_type | |
| Public Attributes inherited from ReferenceCount | |
| get_ref_count | |
| Returns the current reference count. More... | |
| Static Public Attributes inherited from TypedWritable | |
| static TypedWritable *const | Null = nullptr |
Detailed Description
This is a specialization on VertexTransform that returns the transform necessary to move vertices as if they were assigned to the indicated joint.
The geometry itself should be parented to the scene graph at the level of the character's root joint; that is, it should not be parented under a node directly animated by any joints.
Multiple combinations of these with different weights are used to implement soft-skinned vertices for an animated character.
Definition at line 33 of file jointVertexTransform.h.
Constructor & Destructor Documentation
◆ JointVertexTransform()
| JointVertexTransform::JointVertexTransform | ( | CharacterJoint * | joint | ) |
Constructs a new object that converts vertices from the indicated joint's coordinate space, into the other indicated joint's space.
Definition at line 36 of file jointVertexTransform.cxx.
Member Function Documentation
◆ accumulate_matrix()
|
virtual |
Adds the value of this transform's matrix, modified by the indicated weight, into the indicated accumulation matrix.
This is used to compute the result of several blended transforms.
Reimplemented from VertexTransform.
Definition at line 78 of file jointVertexTransform.cxx.
◆ complete_pointers()
|
virtual |
Receives an array of pointers, one for each time manager->read_pointer() was called in fillin().
Returns the number of pointers processed.
Reimplemented from TypedWritable.
Definition at line 114 of file jointVertexTransform.cxx.
◆ get_joint()
|
inline |
Returns the joint for which this object returns the transform.
Definition at line 18 of file jointVertexTransform.I.
◆ get_matrix()
|
virtual |
Stores the transform's matrix in the indicated object.
Implements VertexTransform.
Definition at line 57 of file jointVertexTransform.cxx.
◆ mult_matrix()
|
virtual |
Premultiplies this transform's matrix with the indicated previous matrix, so that the result is the net composition of the given transform with this transform.
The result is stored in the parameter "result", which should not be the same matrix as previous.
Reimplemented from VertexTransform.
Definition at line 68 of file jointVertexTransform.cxx.
◆ register_with_read_factory()
|
static |
Tells the BamReader how to create objects of type JointVertexTransform.
Definition at line 94 of file jointVertexTransform.cxx.
References BamReader::get_factory(), and Factory< Type >::register_factory().
Referenced by init_libchar().
◆ write_datagram()
Writes the contents of this object to the datagram for shipping out to a Bam file.
Reimplemented from VertexTransform.
Definition at line 103 of file jointVertexTransform.cxx.
References VertexTransform::write_datagram(), and BamWriter::write_pointer().
The documentation for this class was generated from the following files:
- panda/src/char/jointVertexTransform.h
- panda/src/char/jointVertexTransform.cxx
- panda/src/char/jointVertexTransform.I
